GST I-9319 Intelligent Adresli Bölge Monitor Modülü

★★★★★ (0 Değerlendirme)

Marka

: GST

Stok Kodu

: I-9319

Stok Durumu

: Mevcut

Kargo Ücreti

: Ücretsiz Kargo

6,108.90 TL

Ürün Açıklaması

Açıklama

GST I-9319 Intelligent Adresli Bölge Monitor Modülü

Feature
☆Interfaces with conventional fire detection equipment/panels etc
☆ Can connect up to 15 detectors with Active EOL or up to 25 detectors with Resistor EOL
☆ Ideal for integrating Sprinkler Zone Valve and Flow Switches
☆ Electronically addressed
☆LPCB Approved
Technical Specifications
☆ Operating Voltage: 24VDC Loop, 24VDC Power Supply
☆ Operating Current:
Loop: Standby Current 0.5mA, Alarm Current 5mA
Power Supply: Standby Current 10mA, Alarm Current 60mA
☆ Capability: 15 conventional detectors
☆ End of Line: 4.7kΩ resistor or AEOL
☆ Action Resistance: 470 ~ 680Ω
☆ Operating Environment:
Temperature: -10℃ ～+50℃
Relative Humidity: 95%
☆ Dimension: 120mm x 80mm x 43mm
